ER4043 - Aluminum TIG Welding Rod Sizes: 1/16"- 1/8" X 36"
ER4043 - Aluminum TIG Welding Rod Sizes: 1/16"- 1/8" X 36"
SKU:ER4043-1/16-1lb
Regular price
$12.99 AUD
Regular price
$15.99 AUD
Sale price
$12.99 AUD
Taxes included.
Quantity
Couldn't load pickup availability
Secure payments
All payments are processed securely. We do not store card details.
Prices include GST for Australian customers.
ER4043 - Aluminum TIG Welding Rod Sizes: 1/16"- 1/8" X 36"
Sizes:
1/16" - 3/32" X 36" - 1 lb tubes
Approximate Number of Rods Per Tube:
1/16" - About 34-37 rods per 1lb tube
3/32" - About 15-17 rods per 1lb tube
1/8" - About 10-15 rods per 1lb tube
| AWS | A5.10 Grade |
|---|---|
| Class | ER 4043 |
| Diameter | 1/16", 3/32", 1/8" |
| Length | 36" |
| Weight |
1 lb, packs |
Description and Applications Inweld 4043 is a silicon-aluminum wire for welding of 5052 and 6063 types; in some cases, other aluminums are also welded with this type. Silicon content is 5%. Inweld 4043 can also be used for welding 3003, 3004, 6061, and casting alloys 43, 355, 356, and 214. Brazing of 1100 and 3003 can be accomplished with free flowing 4043 composition.
The post-anodizing color tint is gray.
Typical Weld Metal Properties AWS Spec
Tensile Strength: 44,000 psi
Yield Strength: 40,000 psi
Elongation: 17%
